Wide Angle to Frame Everyone in the Picture
The 4K UHD video resolution of the C30R all-in-one conference camera creates a sense of being in the same room as others, while the 120° super wide angle lens ensures that everyone is included in the frame.
Frame You at the Center of the Picture for Meeting Freedom
C30R’s Proprietary AI algorithms power features such as auto-framing, close-up group, and speaker tracking, creating a more engaging and efficient meeting experience.
Tech Specs
| Camera features |
- Aperture: F/1.8
- Sensor: Sony 1/2.8 inches CMOS
- Maximum pixels: 8MP
- 6x digital zoom
- FOV(D):120°
- FOV(H): 110°
- FOV(H): 75°
|
| Video characteristics |
- Lens distortion correction supported
- Anti-flickering supported
- Automatic white balance and exposure supported
- 3D noise suppression supported
- 4K UHD image
- Aspect ratio: 16:9
- YUV：max of 480P@30fps
- MJPEG：max of 1080P@30fps
- H264：max of 2160P@25fps
- Speaker tracking supported
- Closeup group supported
- Auto-framing supported
|
| Microphone Characteristics |
- 5 MEMS microphone array
- Effective pickup distance: 5m(16ft)
- Sensitivity: -38dBV/Pa 94dB SPL@1kHz
- SNR: 63dBV/Pa 94dB SPL@1kHz,A-weighted
|
| Speaker characteristics |
- Rated output power: 4Ω/5W
- Speaker frequency response: 160Hz ~20kHz
- Speaker volume: 80±3dB @1m
- THD≤3%
|
| Audio Features |
- Direction of arrival（DOA）supported
- Beamforming supported
- AI noise suppression
- Full-duplex
- Echo cancellation
- Automatic Gain Control(AGC)
- Reverberation suppression
|
| Daisy-chain |
|
| Physical characteristics |
- Height: 81mm (3.2 inches)
- Width: 570mm (22 inches)
- Depth: 77mm (3 inches)
- Net weight: 2010g(70.9 oz)
- Gross weight: 3410g
- Color: lunar rock gray
- Mounting Options: Desktop stand(default)
- TV bracket(optional) / Wall bracket(optional)
|
| Power and connectivity |
- External power supply: DC 48V/1.35A
- Compatible operating systems: Windows/Mac/Linux
- USB port: USB 2.0 Type-C
|
